Feature
l Supports 9.95Gb/s to 11.3Gb/s bit rates
l Hot Pluggable XFP Footprint
l 850nm VCSEL Laser and PIN photo detector
l
Up to 300M transmission on SMF
l Power dissipation < 2W
l Single Power Supply: 3.3V
l No Reference Clock Required
l Compatible with RoHS
l Built-in Digital Diagnostic Functions
Application
l 10Gb/s Ethernet(10.3Gb/s)
l 10Gb/s Ethernet with FEC(11.1Gb/s)
l 10G Fibre Channel(10.5Gb/s)
l 10G Fibre Channel with FEC(11.3Gb/s)
l Fibre Channel over Ethernet(10.3Gb/s)
Outline drawing (mm):
Optical Characteristics
(Ambient Operating Temperature -5°C to +70°C, Vcc =3.3 V)
|
Parameter |
Symbol |
Min. |
Typ. |
Max. |
Units |
|
Transmitter Section |
|||||
|
Center Wavelength |
lo |
840 |
850 |
860 |
nm |
|
RMS Spectral Width |
Dl |
- |
- |
0.45 |
dB |
|
Average Output Power |
Po |
-5 |
- |
-1 |
dBm |
|
Extinction Ratio |
Er |
3.5 |
- |
- |
dB |
|
Jitter(p-p) |
|
|
|
0.1 |
UI |
|
Relative Intensity Noise |
RIN12OMA |
|
|
-128 |
dB/Hz |
|
Receiver Section |
|||||
|
Center Wavelength |
lo |
|
850 |
|
nm |
|
Receiver Sensitivity |
Rsen |
|
|
-11.5 |
dBm |
|
Stressed Sensitivity |
Rsen |
|
|
-10.5 |
dBm |
|
Receiver Overload |
Rov |
0 |
|
|
dBm |
|
Return Loss |
|
12 |
|
|
dB |
|
LOS Assert |
LOSA |
-25 |
|
|
dBm |
|
LOS Dessert |
LOSD |
|
|
-13 |
dBm |
|
LOS Hysteresis |
|
0.5 |
|
4 |
|
For detail, please check the datasheet in "Download".
