WT-SFP+-CWDM-40KM

model： WT-SFP+-CWDM-40KM

10Gb/s CWDM 40KM SFP+ Transceiver

Description Technical parameters Applications Download Related Products

PRODUCT FEATURES

lHot-pluggable SFP+ footprint

lSupports 9.5 to 10.3Gb/s bit rates

lPower dissipation < 1.5W

lSingle 3.3V power supply

lMaximum link length of 40km

lCWDM wavelength EML transmitter, PIN photo-detector

lDuplex LC connector

lPower dissipation < 1.5W

lBuilt-in digital diagnostic functions

lCase temperature range ?-5°C to 70°C

Applications

l10GBASE-ZR/ZW 10G Ethernet

STANDARD

lCompliant with SFF-8472 SFP+ MSA.

lCompliant to SFP+ SFF-8431 and SFF-8432.

lCompliant to 802.3ae 10GBASE-ER.

lRoHS Compliant

Outline Dimensions

Label： SFP+

Optical Characteristics

Parameter	Symbol	Min.	Typ.	Max.	Unit	Note
Transmitter
Average Launched Power	PO	0		+5	dBm	Note (1)
Extinction Ratio	ER	6			dB
Center Wavelength	λc	1470		1610	nm
Center Wavelength Space			20		nm
Spectrum Band Width (RMS)	σ			1.0	nm
SMSR		30			dB
Transmitter OFF Output Power	POff			-40	dBm
TX Jitter (peak-peak)	Txj			0.1	UI
TX Jitter (RMS)	Txjrms			0.01	UI
Transmitter andDispersion Penalty	TDP			3.0	dB
Output Eye Mask	Compliant with IEEE 0802.3ae
Receiver
Input Optical Wavelength	λ	1270		1610	nm
Receiver Sensitivity				-14	dBm	Note (2)
Input Saturation Power (Overload)	Psat	0.5			dBm
LOS Detect -Assert Power	PA	-21			dBm
LOS Detect - Deassert Power	PD			-19	dBm
LOS Detect Hysteresis	PHYS	2			dB

For detail, please check the datasheet in "Download".
